重型鋼板網
分享:
0318-7593111
| Type | Pattern | （mm） Mesh size | （mm） Strand size | Weight kg/m2 | Size L×S(mm) Weight（kg/sheet） | ||||
| 914×1829 | 1219×2438 | 1524×3048 | |||||||
| SWD | LWD | T | W | ||||||
| XS(XF) | XS31 | 12 | 30.5 | 1.2 | 1.5 | 2.36 | 3.95 | 7.01 | 11.0 |
| XS32 | 12 | 30.5 | 1.6 | 2.0 | 4.19 | 7.01 | 12.5 | 19.5 | |
| XS33 | 12 | 30.5 | 2.3 | 3.0 | 9.03 | 15.1 | 26.8 | 41.9 | |
| XS41 | 22 | 50.8 | 1.6 | 2.0 | 2.28 | 3.81 | 6.78 | 10.6 | |
| XS42 | 22 | 50.8 | 2.3 | 2.5 | 4.10 | 6.86 | 12.2 | 19.0 | |
| XS43 | 22 | 50.8 | 3.2 | 3.5 | 8.00 | 13.4 | 23.8 | 37.2 | |
| XS51 | 25 | 61.0 | 1.6 | 2.5 | 2.51 | 4.20 | 7.46 | 11.7 | |
| XS52 | 25 | 61.0 | 2.3 | 3.0 | 4.33 | 7.24 | 12.9 | 20.1 | |
| XS53 | 25 | 61.0 | 3.2 | 4.0 | 8.05 | 13.5 | 23.9 | 37.4 | |
| XS61 | 34 | 76.2 | 2.3 | 3.0 | 3.19 | 5.33 | 9.48 | 14.8 | |
| XS62 | 34 | 76.2 | 3.2 | 4.0 | 5.91 | 9.88 | 17.6 | 27.5 | |
| XS63 | 34 | 76.2 | 4.5 | 5.0 | 10.4 | 17.4 | 30.9 | 48.3 | |
| XS71 | 50 | 152.4 | 2.3 | 3.5 | 2.53 | 4.23 | 7.52 | 11.8 | |
| XS72 | 50 | 152.4 | 3.2 | 4.0 | 4.02 | 6.72 | 11.9 | 18.7 | |
| XS73 | 50 | 152.4 | 4.5 | 5.0 | 7.06 | 11.8 | 21.1 | 32.8 | |
| XS81 | 75 | 203.2 | 3.2 | 4.0 | 2.68 | 4.48 | 7.96 | 12.4 | |
| XS82 | 75 | 203.2 | 4.5 | 5.0 | 4.71 | 7.88 | 14.0 | 21.9 | |
| XS83 | 75 | 203.2 | 6.0 | 6.0 | 7.54 | 12.6 | 22.4 | 35.0 | |
| XS91 | 115 | 304.8 | 3.2 | 5.0 | 2.18 | 3.64 | 6.48 | 10.1 | |
| XS92 | 115 | 304.8 | 4.5 | 6.0 | 3.69 | 6.17 | 11.0 | 17.1 | |
| XS93 | 115 | 304.8 | 6.0 | 7.0 | 5.74 | 9.60 | 17.1 | 26.7 | |
材質:低碳鋼(Q195/Q235)、不銹鋼、黃銅板、鋁鎂合金板。
鋁板，鈦板，鎳板。
過程和特點:沖壓、拉伸、壓平,美觀,耐用,耐蝕性好,防滑,可見性和豐富多彩。
由于重型膨脹金屬的高強度，主要用于人行道、坡道、t型臺、工作臺、機器防護罩、格柵、臺階網、建筑加固、護欄等。
